Sleeve boxes

Boxes with Sleeves – Greater Possibilities

Our boxes with sleeves offer a unique solution that combines aesthetics with practicality. Made from corrugated cardboard in white, gray, or black, they ensure durability and stylish presentation. The sleeve, being a key element of the product, gives the boxes a unique character, highlighting their contents.

Standard sleeve designs are crafted to cover the entire box and easily slide along the longest side. This allows us to offer quick and convenient solutions tailored to various needs.

For more demanding projects, there is an option for custom sleeves, which can be shaped according to the Client's expectations.

Available in various color variants, the boxes and sleeves are an excellent solution for both product packaging and creating attractive advertising presentations.

Why Choose Boxes with Sleeves?

Durability and Aesthetics – made from corrugated cardboard in three color variants.
Universal and Customized – standard designs or the possibility of custom projects.
Ease of Storage – delivered flat, ready for quick assembly.

Technical Parameters of Boxes with Sleeves

Material:

Boxes: corrugated cardboard in white, gray, or black color.
Sleeves: standard coated paper 250g/m². Possibility of using decorative papers.

Standard Sleeves:

Cover the entire box, applied along the longest side.
Templates available for download in the "How to Prepare" section or in the calculator.

Custom Sleeve Option:

Possibility to prepare sleeves of non-standard width or shape.
Condition: the design must fit within the standard template for a given box.
Feature available in the calculator as "Custom Shape Sleeve."

Delivery and Storage:

Boxes and sleeves are delivered flat.
Sleeves are scored and glued, ready for quick assembly.

Enhancements:

Possibility of additional enhancement of sleeves, e.g., lamination, UV varnish, Liquid Gold.

Dimensions of Available Boxes

Name	External Dimensions			Internal Dimensions
Name	width	depth	height	width	depth	height
Die-cut 144 x 105 x 66 gray	160	110	70	144	105	66
Die-cut 144 x 105 x 66 white	160	110	70	144	105	66
Die-cut 180 x 120 x 40 gray	200	125	45	180	120	40
Die-cut 180 x 120 x 40 white	200	125	45	180	120	40
Die-cut 200 x 150 x 50 gray	220	155	55	200	150	50
Die-cut 200 x 150 x 50 white	220	155	55	200	150	50
Die-cut 155 x 105 x 110 black	160	110	115	155	105	110
Die-cut 235 x 170 x 45 black	248	170	45	235	170	45

Dimensions of available boxes may change over a longer period of time.

How to Prepare Files for Boxes with a Sleeve

Standard Sleeve

Download the appropriate template and design the file for printing and finishing based on it.
Depending on the order, prepare one or two files:
- 1 file - if the sleeve is not finished.
- 2 files (or one two-page) - if there is finishing with UV varnish, Liquid Gold, or Silver.
Detailed file preparation rules can be found in the HELP section.
Attach only the graphic design to the order, without the template.

Non-standard Sleeve (narrower / any shape)

For non-standard shapes, it is recommended to download the standard sleeve template, which will help in preparing your own design.
Template modification:
- Cutting lines - modify so that the new shape fits within the standard template.
- Creasing lines - do not change their position, you can only shorten their length.
The order should include the graphic file along with the cutting template.

All additional technical details can be found in the HELP section.
